GREENBOLT DCFC Series

GREENBOLT DCFC Series – Ultra-Fast DC Charging Solutions

The GREENBOLT DCFC Series offers high-performance, ultra-fast DC charging solutions designed for modern commercial, industrial, and public EV infrastructure. Engineered for maximum efficiency and reliability, the GREENBOLT DCFC chargers deliver rapid power output, making them ideal for EV fleets, public stations, malls, parking structures, and highway charging networks.

This series is built to minimize charging time while maintaining strong safety, durability, and connectivity standards—ensuring a seamless charging experience for both operators and EV drivers.

Key Features & Benefits

• Ultra-Fast Charging Performance
  Delivers high-power DC output (varies by model), drastically reducing EV charging time compared to standard AC chargers.
• Commercial-Grade Reliability
  Designed for continuous, heavy-duty operation, making it suitable for public and fleet environments with high traffic.
• Real-Time Monitoring
  Integrated display shows key charging parameters including voltage, current, power output, and charging status.
• Advanced Connectivity
  Supports OCPP, Wi-Fi, Ethernet, and optional 4G/LTE for remote monitoring, management, and diagnostics.
• Flexible Deployment
  Available in multiple power ratings (20kW–180kW+) to accommodate various commercial or semi-public installation needs.
• High Efficiency
  Uses intelligent power modules for stable performance and optimized energy usage.
• Weatherproof & Durable
  IP55/IP65 protection rating (depending on model) ensures dependable operation in outdoor and harsh conditions.
• Enhanced Safety
  Built-in protections such as overvoltage, undervoltage, overcurrent, surge protection, overheating safeguards, emergency stop, and automatic fault recovery.

Specifications Sheet (General Series Specifications)

• Series Name: GREENBOLT DCFC – DC Fast Charger Series
  Charging Type: DC Fast Charging
  Available Power Options: 20kW, 30kW, 60kW, 120kW, 150kW, 180kW+ (model-dependent)
  Output Voltage Range: Typically 200V – 1000V (varies per model)
  Charging Interface: CCS1 / CCS2 / CHAdeMO (optional per configuration)
  Efficiency: ≥ 95%
  Connectivity: OCPP 1.6J / OCPP 2.0, Wi-Fi, Ethernet, optional 4G
  Display: 7"–10" LCD screen (depends on model)
  Weather Resistance: IP55 or IP65 (model-dependent)
  Operating Temperature: -30°C to 50°C
  Cooling Method: Intelligent air cooling or liquid cooling (on high-power models)
  Installation: Floor-standing
  Safety Certifications: CE, UL, RoHS compliance
  Warranty: 2-year standard warranty (extendable)
